GitHub Flavored Markdown: the complete guide

Tables: structured data in plain text

Tables are the extension people miss most in plain Markdown. Pipes (|) separate the columns. A divider row of hyphens splits the header from the body. Colons inside that divider row set the alignment.

| Feature       | Original MD | GFM |
|:--------------|:-----------:|----:|
| Tables        |     No      | Yes |
| Task lists    |     No      | Yes |
| Strikethrough |     No      | Yes |

How the divider row controls alignment

One row does all the work. Read each colon as a magnet pulling the text toward it:

• :--- or a plain --- aligns the column left. That is the default.
• :---: centers it, which suits short status words like Yes and No.
• ---: pushes it right. That is what you want for numbers and prices.

The pipes do not have to line up on screen. The parser only checks that they are there. Neat source is still worth the extra spaces, because the next person to edit the file has to read it as raw text.

Where GFM tables stop

The syntax is deliberately small. There are no merged cells and no nested tables, and a cell cannot hold a real line break. Escape a literal pipe as \| or it will be read as a column edge. For a break inside a cell, use a <br> tag instead.

Tables are also the construct that breaks most often in practice. The Markdown tables guide covers the escaping rules, generators, and the point where an HTML table is simply the better tool.

Task lists: checkboxes in your documents

A task list is an ordinary bulleted list whose items begin with [ ] for an open task or [x] for a finished one. Two spaces decide whether it works: one inside the empty brackets, one after the closing bracket.

## Release checklist

- [x] Update the changelog
- [x] Bump the version number
- [ ] Tag the release
- [ ] Publish release notes
    - [ ] Nested subtasks work too

Clickable checkboxes on GitHub

The real prize is that task lists can be interactive. In issues, pull request descriptions and comments, the rendered boxes are clickable. Tick one and GitHub edits the underlying Markdown for you. It also shows a running count, such as "3 of 5 tasks", in issue lists and wherever the pull request is referenced. Notion, Obsidian and many to-do apps treat the same syntax as live checkboxes.

Read-only checkboxes everywhere else

In static output the boxes still render, they just cannot be clicked. That covers a README, a blog post and an exported HTML file. A published checklist is still the clearest thing you can hand a reader, because they can copy the source and reuse it.

Subtasks follow the normal nesting rules, so the normal nesting traps apply. Indent the child item under the text of its parent, and never mix tabs with spaces. The Markdown lists reference spells out how many spaces each renderer expects.

Strikethrough, autolinks and HTML filtering

Three smaller extensions finish off the spec. Two of them add syntax. The third takes something away, on purpose.

Strikethrough with double tildes

Strikethrough wraps text in two tildes, so ~~like this~~ renders as crossed-out text. It is the honest way to show a correction: ~~$99~~ $79 keeps the old price in view. It also marks a line as done without deleting what it said.

Autolinks for bare URLs and emails

Autolinks save you the bracket dance. In original Markdown, a bare address such as https://mdeditor.tw is inert text unless you wrap it in angle brackets or full link syntax. GFM spots bare web and email addresses and makes them clickable on its own.

That is a gift in issue comments and a small trap in polished documents. A raw URL tells the reader nothing about where it leads, so descriptive link text like [MD Editor](https://mdeditor.tw) still reads better.

Disallowed raw HTML

The raw-HTML filter is the one extension that removes rather than adds. Markdown has always let you drop HTML straight into a document, which is a large part of what the Markdown and HTML comparison is about. On a site where millions of strangers write comments, that freedom is a security hole.

So the GFM spec filters a fixed list of dangerous tags: <script>, <title>, <textarea>, <style>, <iframe>, <xmp>, <noembed>, <noframes> and <plaintext>. It escapes the opening bracket, so the tag shows up as text instead of running. Ordinary presentational HTML such as <br>, <sub> and <details> still works fine.

Watch out: This filter is why a video embed that works on your own blog disappears from a GitHub README. Nothing warns you. The <iframe> is simply not there in the rendered page.

Syntax highlighting in fenced code blocks

A fenced code block is three backticks, your code, then three backticks again, and everything between the fences is kept verbatim. What turns that grey box into colored code is the language identifier: one short word typed straight after the opening fence, with no space between them.

```python
def greet(name):
    print(f"Hello, {name}")
```

```js
const greet = (name) => console.log(`Hello, ${name}`);
```

GitHub picks the colors using Linguist, its open-source language-detection library. It is the same component that draws the language bar on every repository page. Linguist knows several hundred languages along with their common aliases, so py and python reach the same highlighter.

Type an identifier it does not recognize and nothing breaks. No error appears either. The block degrades to a plain monospaced code block, exactly as if you had written no identifier at all. Fences have a handful of other rules worth knowing, and the code blocks reference collects them in one place.

The identifiers you will actually use

diff blocks beat describing the change

diff deserves to be learned on its own. Start a line with + for an addition or - for a removal, and GitHub tints the lines green and red:

```diff
- const port = 3000;
+ const port = process.env.PORT || 3000;
```

Turning highlighting off on purpose

At the opposite end sits text, also spelled plaintext. Its whole job is to switch coloring off. Reach for it with terminal output, log excerpts, directory trees and ASCII diagrams. Set a highlighter loose on those and it will invent syntax that is not really there.

Highlighting is a renderer feature, not a Markdown feature

This caveat matters more than any identifier in the table. Neither CommonMark nor the GFM spec says a fence must be colorized. The spec only says the text after the fence is an "info string" that a renderer may use.

In practice that string becomes something like class="language-python" on the <code> element, and a stylesheet or a highlighting library takes it from there. So results differ by tool:

• GitHub and GitLab highlight the block for you.
• A bare CommonMark parser does not, and never claimed it would.
• Static site generators highlight only once you wire up Prism, highlight.js or Chroma.

Our own Markdown editor highlights the block too. It uses highlight.js, loaded only when a document actually contains code. A fence that carries a language tag gets colored; a fence with no tag is left plain on purpose, because a guessed language colors the code wrong.

Tip: Label every fence, even one holding shell output. text tells the next reader the block is meant to stay uncolored, and it stops a future tool from guessing wrong.

Mermaid diagrams from a plain code fence

Mermaid is the most striking thing GitHub does with an info string. Label the fence mermaid and GitHub does not highlight the block at all. It renders the contents as a real diagram:

```mermaid
graph TD;
  A[Write Markdown] --> B[Commit];
  B --> C[GitHub renders the diagram];
```

Flowcharts, sequence diagrams, class diagrams, state diagrams and Gantt charts all work this way. Each one lives in the repository as plain text and diffs like any other file. GitLab, Notion and Obsidian support Mermaid too. Renderers that do not simply show the source as an ordinary code block.

You can test the block above without leaving this site. Paste it into the Markdown editor and the preview draws the diagram. If the Mermaid source has a typo in it, the fence stays a code block instead of throwing an error at you, so a half-written diagram never breaks the rest of the preview.

Math blocks with $ and $$

GitHub also parses LaTeX-style math. Inline math sits between single dollar signs, as in $E = mc^2$. A display block sits between double dollar signs on their own lines:

$$
\frac{1}{n}\sum_{i=1}^{n} x_i
$$

GitHub renders these with MathJax in READMEs, issues, comments and wikis. A stray dollar sign in ordinary prose can be mistaken for the start of a formula, so escape a literal one as \$. Math depends on the renderer in exactly the way highlighting does. It works on GitHub and in Obsidian, Typora and Pandoc, while a plain CommonMark parser prints the dollar signs as text.

The editor on this site renders math as well, using KaTeX. It accepts $inline$ and $$display$$, plus the \(...\) and \[...\] delimiters that LaTeX users type by habit. So you can check a formula here first, then paste it into a README.

GFM vs CommonMark vs original Markdown

The three names get mixed up constantly, so here is the family tree:

• Original Markdown (2004) is John Gruber's Perl script plus an informal syntax page. Groundbreaking, but vague enough that parsers argued over edge cases for a decade.
• CommonMark (2014) is the standardization effort. It settles every ambiguity with a formal spec and hundreds of test cases, and deliberately adds no new features.
• GFM (spec 2017) is CommonMark plus GitHub's extensions. That is why anything able to parse GFM also parses CommonMark perfectly.

Feature by feature

So which one should you write?

Write GFM. It fails gracefully, because a table shown in a CommonMark-only renderer looks like a few odd pipes rather than a broken page. It is also the dialect your teammates, your tools and your future self are most likely to expect.

The exception is a destination you do not control and cannot test. When you are unsure what the far end supports, stay on headings, lists, links and emphasis, which every dialect handles the same way. Our online editor previews full GFM, so you can check a README, an issue comment or a wiki page before you publish it.
